E37-15A Type 1 ATC Circuit Breaker 15 Amps
Click or scroll to zoom
Tap or pinch to zoom
E37-15A Type 1 ATC Circuit Breaker 15 Amps
E37-15A Type 1 ATC Circuit Breaker 15 Amps

E37-15A Type 1 ATC Circuit Breaker 15 Amps

by Connector ID
$2.19
We have 0 in stock. Lead time: Contact Us

Pricing (USD) - Contact Us for Volume Pricing

  • 1-24 Pieces ($2.19 / Pc)
  • 25-99 Pieces ($1.78 / Pc)
  • 100-499 Pieces ($1.78 / Pc)
  • 500+ Pieces ($1.66 / Pc)
Description
  • Minimum Order Qty: 1 pc
  • Brand: Song Tang
  • Connector ID Part Number: E37-15A
  • Product Type: 15 Amp Type 1 (Auto Reset) ATC Circuit Breaker Low Profile
  • Application: Compatible with ATC Fuse Blocks
  • Voltage: 14 Vdc
  • Operating Termperature: -40ºC (-40ºF) to 85ºC (185ºF)
  • Interupt Capacity: 2,000 Amp @28Vdc
  • Complaince: SAE J553 and SAE J1171 for ignition protection
  • Weight: 5 gram
  • Termination: 5.2 mm wide blades (ATC Type)
  • HTS Code: 8536200040
  • Standard Carton Qty: 1,500 pcs
