Rennsteig 6950002RT PEW 15 Hand Crimp Tool Without Die Set
Sold out
Original price
$413.00
-
Original price
$413.00
Original price
$413.00
$413.00
-
$413.00
Current price
$413.00
Hand crimp tool for 9.5 mm and 8.0 mm power sealed & unsealed terminals.
| Rennsteig Part No. | 695 000 2 |
| Minimum Order Qty: | 1 unit |
Features:
- Interchangeable crimping dies and locators for a wide range of power terminals.
- Die set and locator are sold separately.
- Low hand force with efficient lever action.
- Crimping force of 15 kN.
- Forced-lock completion of the crimping process to ensure reliable crimping results
- Emergency release
- Re-adjustable crimp pressure
- One & two-handed operation
- Lightweight aluminum body
- Plastic-coated grips.
Associated Die Sets:
Die set and locator are sold separately.
| Part No. | DESCRIPTION |
| 695001301 | Die Set & Locator for Aptiv Ducon F9.5 with seal 15327010-L (4.0 mm²) |
| 695002301 | Die Set & Locator for Aptiv Ducon F9.5 with seal 15327010-L (6.0 mm²) |
| 695003301 | Die Set & Locator for Aptiv Ducon F9.5 with seal 10730408-L (10.0 mm²) |
| 695025301 | Die Set & Locator for Yazaki YESC 9.5 with seal 7116-3250, 7114-3250 (6.0 mm² / 8 AWG) |
| 695030301 | Die Set & Locator for TE Maxi Power Timer 962932 & 962933 (10.0 mm²) |
| 695032301 | Die Set & Locator for TE Maxi Power Timer with seal 962938 & 962939 (6.0 -10.0 mm²) |
| 69504330 | Die Set for MTA F800 1707650-L & 1707620-L (1.5 - 2.5 mm²) |
| 69504430 | Die Set for MTA M800 / WP M800 1707675-L & 1707700-L (4.0 mm²) |
| 69504530 | Die Set for MTA F800 1707660-L (6.0 mm²) |
| 69504630 | Die Set for MTA M800 / WP M800 1707685-L & 1707710-L (6.0 mm²) |
| 695647301 | Die Set and Locator for TE Maxi Power Timer with seal, 962936 & 9637772, (4.0 - 6.0 mm²) |
